Product Parameter:
Intelligent single chip design, support ADAS, DSM, BSD
H.265 encoding, high compression ratio, clear image, save memory space
Support 4ch AHDs,1ch IPC
AHD/TVI/CVI/IPC/ analog five video inputs
Supports 4-way 25 frame real-time encoding
Support CAN
Built-in G-Sensor to monitor vehicle driving behavior in real time
Support the auxiliary astern image ranging
Support image level, mirror adjustment
Unique GPS drift suppression algorithm
Input pulse automatic calibration algorithm
Support Yunweibao debugging and maintenance
Power supply:
Professional car power supply 9-36V DC wide voltage input design
Undervoltage, short circuit, reverse connection and other protection circuit, suitable for all kinds of models
Support intelligent power management identification, low power automatic shutdown, flame out low power consumption
Data storage:
Built-in ultracapacitor to avoid data loss and disk damage due to abnormal power outages
Adopt special file management mechanism, encrypt data, effectively protect data security
Support double SD card storage, the maximum support single card 512G
Wireless module:
Built-in GPS/BD/GLONASS module, high sensitivity, fast positioning
Built-in 4G module, support LTE/HSPA/WCDMA
Active security early warning system:
Built-in ADAS Advanced Driver assistance system (collision, vehicle proximity, lane departure, etc.)
Built-in DSM driver status analysis system (fatigue, distraction, smoking, talking on the phone, driver anomaly, occlusion, driver contrast, etc.)
Built-in BSD (optional) blind area monitoring system (Level 3 alarm)
Support remote calibration function of operation and maintenance platform
Driving behavior detection
Support harsh acceleration, harsh deceleration, harsh turn
Support rollover, collision alarm
