Product Parameter:
Support 4CH 1080P/720P/D1 camera input and automatically segment the image
Support MAX 512G TF card
CVBS/AHD1080P Output Optional (Aviation head). AHD1080P output backward compatibility(720P/1080P 25/30fps)
Can be adjusted independently for brightness.Contrast.saturation.hue and sharpness of each channel
4CH camera can be triggered separately and displayed in full screen automatically
The video output can be set TOP/Bottom/Left and Right deflate
Output power to cameras and monitor (12V)
Each image normal/mirror function can be set separately
Box working voltage :9V-32V
High and low voltage and overload protection
Video output connector: 4PIN aviation
Support audio output
Can choose image of any channel of 4 cameras by trigger wire or hand
After cancelling trigger.the image is delayed for 2 sec. and returns to the state before the trigger
Support PAL/NTSC video format
Dimension: 155*87*32mm
