Product Parameter:
Built-in high performance chipsets, coded with H.265 standard, high compression rate and image quality
AHD/TVI/CVI/IPC/ANALOG/IPC five in one video input, wide compliance
4+1 live preview and storage
1CH synchronized AV output, 1CH VGA output
Hard Disk Auto-Heating (Optional)
Support UPS power input
Built-in G-sensor, monitor the driving habits
Reverse Assistance
Adjust the camera image horizontally and vertically
Power:
Professional In-Vehicle power design,8-36V DC Wide Voltage Range
Multiple protection circuits like under-voltage, short, reversed plug-in
Smart power management system, shutdown under low voltage, low consumption when standby
Report the GPS info to the server regularly with very low power consumption, compliant with JT/T794-2011 standard
Data Storage:
Built-in super capacitor to avoid data loss and disk damage caused by sudden outage
Special file management system to encrypt and protect the data
Proprietary technology to detect the bad track of the disk which can make sure the continuity of video and long service life of the disk
Support 2.5 inch HDD/SSD, maximum 2TB
Support SD card storage, maximum 512GB
Transmission Interface:
Support GPS/BD/GLONASS optional, high sensitivity, fast positioning
Support wireless download by WiFi, 802.11b/g/n, 2.4GHz
Support 3G/4G transmission, LTE/HSUPA/HSDPA/WCDMA/EVDO/TD-SCDMA
