Name：5 inch Bus/Truck/Van AHD Car Monitors with 1AV Input

Model：CL-530AHD

Category：AHD Monitors

Brief：

* 5 inch digital panel, 16 : 9 image ratio, 800xRGBx480 resolution.

* 2 AHD video inputs and trigger wire for V2 on reversing

* Compatible with CVBS/AHD720P/AHD1080P camera, PAL/NTSC auto switch

* Menu support guideline delay, mirror image, etc setting

Description Parameters

CL-530AHD 5 inch AHD car camera
This Carleader’s 5 inch AHD car camera can provide 1024P display.
CL-530AHD has 2 video inputs and 2 trigger wire which could be compatible with CVBS&720P&960P&1080P HD 25/30fpsP/N video inputs.

Carleader 5 inch AHD Car Camera Parameter

Size	5 inch digital new panel
CDS	Auto dimming function optional
Resolution	800xRGBx480
Screen Type	16:9
Inputs	2 video inputs with 1 trigger wires(default)
Video Input Format	CVBS&720P&960P&1080P HD 25/30fpsP/N video inputs.
Brightness	LED, 400cd/m2
Contrast	700：1
View Angle	L/R:70, UP:50, Down:70 degree
OSD	5 languages, remote control
Built-in Speaker	(Optional)
Power supply	DC 9~32V
0~10s selection	Guide line and rear view delay

5 inch AHD Car Monitors Feature And Application
CL-530AHD is used in Bus/Truck/Van which is small and could be easily set up.
