Name:23.6 inch Open Frame HD Monitor
Model:CL-236HD
Brief:
The Car Monitor of the CL-270HD uses a high-quality IPS panel with different viewing angles and a resolution of 1920x3(RGB)x1080.
This means users can enjoy precise, detailed images from any angle, making it ideal for displaying images and videos.
Description Parameters
The parameter of 23.6inch Open Frame HD Monitor:

LCD Screen Physical Indicators:

Screen Type

Color TFT LCD Sreen

Size

23.547inch

Viewable size

521.28(H)x293.22(V) MM

Pixel

0.24825(H)x0.24825(V) MM

Resolution

1920x3(RGB)x1080


16.:9

View Mode

TN Mode

View Color

16.7M colors (RGB 6-bits+HiFRC)

Screen signal interface

Double channel LVDS

 LCD Screen Spec:

Viewing angle

85︒/85︒/ 80︒/ 80︒Left/Right/Up/Down

contrast

1000.1

brightness

300cd/

Response time

5msec

Screen backlight

WLED

Backlight life

50000 hours

Other Spec:

Operating temperature range

-20°C~70°C, humidity max 95%

Storage temperature range

-30°C~80°C, maximum humidity 95%

Operating voltage range

DC12V

Working power

52 W

Mode of operation

Remote control, panel button operation

Language

 multi-language

Installation method

Recessed, wall-mounted, desktop stand mounted, etc.

Housing material

Metal housing

Housing Color

Black
